Edoo High Quality Cheap Price Made in China Supermarket Warehouse Store Desktop Handheld Usb Qr 1d 2d Barcode Scanner

Артикул: CN-SCAN-010

Краткое описание

Excellent 1D/2D Barcode Reading Capability Adopt the self-developed core decoding technology, can fastly read large amount of various filmed on-screen 1D/2D barcode.

model numberH41-11-600A

MOQ1

CategoryScanners

UnitUnit

Перейти в подробное описание

Характеристики

model numberH41-11-600A

MOQ1

CategoryScanners

UnitUnit

QR Code 30mm~170mm (15mil)Scan AnglePitch±60°

Roll360°

Image Sensor640H*480V

IlluminationWhite LED

AimingRed LED (625nm)

Symbologies 2DPDF417, Data Matrix, QR Code，Micro QR Code

Symbologies 1DCode 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93, UCC/EAN-128, GS1 Databar, Matrix 2 of 5, Code 11, Industrial 25, Standard 25, ISSN, Plessey, MSI-Plessey,AIM 128 and so on

Reading Precision≥3mil （code128）

Depth of ViewEAN-13 50mm~260mm (13mil)Code 39 50mm~115mm (5mil)QR Code 30mm~170mm (15mil)

Scan AnglePitch: ±60°; Roll: 360°; Skew: ±60°

Symbol Contrast*≥20%（Code 128）

Data InterfaceUSB (HID-KBW、CDC、HID-POS), RS232( need customization )

Size160*95*65mm

Weight180g(including USB cable)

Operation Voltage5.0 VDC±10%

Rated Consumption720mW(Typical)

EnvironmentalOperation Temperature -20℃~60℃

Storage Temperature -40℃~+70℃

Relative Humidity5%~95%（Non-condensing）

CertificationFCC Part15 Class B，CE EMC Class B

Вес180g

модельH41-21

датчик изображения640H*480V

освещениеWhite LED

прицеливаниеRed LED (625nm)

символы 2DPDF417, Data Matrix, QR Code，Micro QR Code

символы 1DCode 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93, UCC/EAN-128, GS1 Databar, Matrix 2 of 5, Code 11, Industrial 25, Standard 25, ISSN, Plessey, MSI-Plessey,AIM 128 и другие

точность считывания≥3mil (code128)

дальность считыванияEAN-13 50mm~260mm (13mil), Code 39 50mm~115mm (5mil), QR Code 30mm~170mm (15mil)

угол сканированияPitch: ±60°; Roll: 360°; Skew: ±60°

контраст символов≥20% (Code 128)

интерфейс данныхUSB (HID-KBW, CDC, HID-POS), RS232 (необходима кастомизация)

размер160*95*65mm

вес180g (включая USB-кабель)

напряжение5.0 VDC ± 10%

потребление720mW (типично)

ток218mA (типичное значение), 234mA (максимальное значение), 52.8mA (в режиме ожидания)

рабочая температура-20℃~60℃

температура хранения-40℃~+70℃

влажность5%~95% (без конденсации)

сертификацияFCC Part15 Class B, CE EMC Class B
